VL64 Vertical Blind with Crank

PART NO VL64

VL64 Vertical Blind with Crank

Ease of use is what makes this blind so delightful. The mono crank control has a comfortable change gear mechanism which allows for an automatic switch from tilting to traversing of the louvres. The strong head-rail and wheeled carrier trucks are designed to withstand the rigours of intensive use. Comes with a choice of 89mm or 127mm louvre widths.

89/127mm louvre widths
Top or face fix brackets
Child safe - mono crank control

Enquire Now Request a quote

Downloads

Brochure Datasheet BIM Model

Product Details Fabric Options System Components

Benefits

The YewdaleDefiant^® VL64 vertical blind has a 45 x 36.5mm white aluminium head-rail with top-fix brackets and wheeled carrier trucks.

The constant transport of the louvres is guaranteed by a precise aluminium spindle shaft.

The fixed crank is operated with built-in slip clutch for both louvre tilt and draw.

Louvres are supplied in 127mm and 89mm widths with weights and white stabilising chain.

Options

VL64S sloping head-rail versions
Face fix brackets
Extension brackets
Enclosed weights
Detachable crank.

Specification

The YewdaleDefiant® VL64 mono vertical blind with crank operation as manufactured by Yewdale, +44 (0)1268 570900. 45 x 36.5mm white powder-coated aluminium head-rail with mono control by crank handle. 127/ 89mm louvres in flame-retardant fabric from the YewdaleDefiant® range, complete with louvre weights and white stabilising chain.

Code	Description	Min Width	Max Width	Max Drop	Max m2
VL64	VL64 Vertical blind with mono crank control	300	4550	3200	14.5

Based on fabric weight of 220g/m², e.g. Thames. Use of heavier fabrics may require appropriate reductions. Sizes shown in millimetres unless otherwise specified.

	Dart	Eden Blackout	Eden Blackout Whiteback	Roach	Roe	Roe Whiteback	Thames	Harrier Disposable	Venetian Aluminium Slats
Dim Out
Black Out
Screen
Fire Retardancy
Suitable for roller blinds
Suitable for vertical blinds
Anti Bacterial
Wipe Clean
Wipe with damp sponge
Suitable for moist conditions
100% Polyester
Dart 14 PVC blackout coloursPerfect for education and healthcare settings Download Datasheet PDF Dart White Dart Vanilla Dart Magnolia Dart beige Dart Grey Dart Iron Dart Bottle Green Dart Mint Green Dart Sky Blue Dart Navy Dart Burgundy Dart Pink Dart Black Dart Black White

Dim Out

Black Out

Screen

Fire Retardancy

Suitable for roller blinds

Suitable for vertical blinds

Anti Bacterial

Wipe Clean

Wipe with damp sponge

Suitable for moist conditions

100% Polyester

Download Datasheet PDF
